AE3710 Ground Resistance Tester
    ¡¤ °í°´¼±È£µµ :
    ¡¤ Á¦Á¶»ç : DAVIS
    ¡¤ Á¦Ç°¹øÈ£:AE3710
    ¡¤ ½ÃÁß°¡°Ý : ¿ø
    ¡¤ ÆǸŰ¡°Ý : ¿ø
    ¡¤ Æ÷ ÀÎ Æ® : Á¡
    ¡¤ ¼ö ·® : °³


¡á
ȸ¿øÀÌ µÇ½Ã¸é °¡°Ýº¯µ¿Á¤º¸, ½ÅÁ¦Ç°, ƯÆÇÁ¦Ç°, ±â¼úÁ¤º¸µî ´Ù¾çÇÑ
´º½ºÁ¤º¸¸¦ º¸³»µå¸³´Ï´Ù.
¡á
¹è¼ÛÀº Æò±Õ 2~3ÀÏÁ¤µµ ¿¹»óµË´Ï´Ù.
                    (0)                     (0)                     (0)
Simple and fast clamp-on operation — no leads, no auxilliary rods or spacing requirements
Features
  • Simple and fast clamp-on operation — no leads, no auxilliary rods or spacing requirements
  • Direct reading of ground resistance from 0.1¥Ø to 1200¥Ø
  • Direct reading of continuity and ground loop resistance
  • Direct reading of ground leakage current from 1mA to 30Arms
  • Jaw design with large 1.25" (32mm) window — accommodates up to 1000MCM cables
  • Auto-off for power management
  • Alarm function with adjustable set point and buzzer for quick field checks (Model 3731)
  • Memory function to store 99 field measurements for later retrieval and analysis (Model 3731)
  • Meets EN 61010-1, Cat. III and CE Mark
  • Rugged Lexan¢ç head and body construction with one-year waranty
  • Alarm settings and stored memory information saved during shutdown (Model 3731) Patented design


CAT NO. MODEL DEscRIPTION AVAIL PRICE
AE3710   3711   CLAMP-ON GROUND RESISTANCE TESTER WITH CARRYING CASE   Yes   4,309,200¡¡
Including: 9 volt battery, calibration loop and instruction manual¡¡
AE3730   3731   CLAMP-ON GROUND RESISTANCE TESTER (WITH ALARM & MEMORY FUNCTIONS)   Yes   4,741,200



With carrying case, 9 volt battery, calibration loop and instruction manual
